| Other Specification | 600 mm Side fly Wheel for high centrifugal inertia.Hopper & Screen Hydraulic openable system,Latest technology V Shape 5 Wings heavy duty Aggressive rotter design.The machine is built by standard material |
| Machine warranty | one-year |
| Housing | In robust, proven construction, two part. Upperhousing part hinged to tower housing part, easy to open with a rack jack after loosening of the hexagon nuts, making the cutting room completely accessible. |
| Shaft & Bearing | Pilow Block Type Bearing Housing With NTN Bearings |
| Knife Rotor | V Shape five wings rotor with Latest technology V Shape Wings heavy impact and shear power. |
| Size Reduction Principle | The material is reduced in size between the rotor knives and the housing knives. The fineness is determined by the mesh size of the screen |
| Hydraulic Openable Housing | Hopper & Screen Hydraulic openable system |
| Slanted feed Chute | In special design for hand feeding PVC Pipes.The PVC Pipes are fed to the rotor from the top,parallel to the rotor axel. The manual feeding could happen from a (customer supplied) platform which is installed at side of the granulator.For easier feeding we recommend to put the granulator |
| Main Motor Drive | 37.3 KW IE2 BBL Induction moto |
| Electrical switch Combination | L & T Switch gear Star delta panel |
| Disclaimer | Above provided all the Technical Specifications like Motor Capacity, Voltage frequency are as per standard scope of supply. But in case of any changes, it will be as perapplication & in order to achieve better results with specified mate |
